Products Description
Touch all-in-one machine product features:
Multifunctionality: The touch all-in-one machine cleverly integrates multifunctional devices such as computers, monitors, projectors, etc., saving valuable space and simplifying complex wiring. Its powerful hardware and operating system can easily handle the operation of various application software, thus meeting your diverse and personalized needs.
High definition display: The touch all-in-one machine is equipped with a high-resolution display screen, which can present clear and realistic images and colors. Whether used to display documents, images, or play videos, it ensures that the content is delicate and exciting, effectively conveying your message.
Fast response speed: The touch all-in-one machine is equipped with top-notch touch screen technology, allowing users to easily operate with their fingers and enjoy a smooth and precise interactive experience. Whether performing clicking, sliding actions, or handwriting input, users can receive instant feedback, bringing an intuitive and convenient operating experience. Provide a smooth experience.
Easy to operate: intuitive and convenient interaction method, reducing operational difficulty and improving information transmission efficiency.
Beautiful appearance: Integrated design, tempered glass protection, high-end aluminum alloy frame, cold-rolled steel plate back shell, simple and elegant appearance, easy to clean and maintain, adjustable base (bracket), users can adjust to the best use angle according to on-site needs, can integrate into various environments.
High reliability: Due to continuous and uninterrupted operation, high reliability is required to ensure long-term stable operation.
Strong adaptability: able to adapt to various working environments, such as factories and outdoor environments, with characteristics such as wide temperature range, dust-proof, waterproof, etc.
Strong expansion function: It can add peripherals such as printing, facial recognition, fingerprint recognition, etc. according to user needs.
Touch all-in-one machine usage:
Business field: applied to shopping malls, restaurants, hotels, etc., such as ordering, payment, shopping guidance, etc.
In the field of education: replacing traditional blackboards as teaching equipment and improving teaching quality.
Public service field: applied to banks, hospitals, stations, etc., such as handling business, querying information, etc.
In the field of industrial production, as a monitoring and control device, it helps enterprises achieve intelligent production.
Meeting function: Used for office purposes such as conference presentations, training, program explanations, remote video conferences, etc.
Electronic whiteboard function: Handwriting can be done on the touch screen without the need for a pen eraser, making it easy to record and demonstrate.
Electronic query function: By entering and editing electronic files and information, customers can self query the required information.
Shopping guide function: Used in shopping malls and public places, providing shopping and visual guidance functions to facilitate customers in finding products.
Tags:
Technical parameter
Screen parameters | Screen size | 49 inches |
Display size | 1073.8*604(H*V)mm | |
Screen resolution | 1920*1080 | |
Contrast ratio | 1500:1 | |
Display color | 1.07B (8-bit+Hi-FRC) | |
Refresh rate | 60Hz | |
Display luminance | 250cd/m² | |
Viewing Angle | Horizontal/vertical: 178°/178° | |
Display configuration | Video input | HDMI:480i,480p,576i,576p,720p,1080i,1080p,4Kx2K@60Hz |
DP:480i,480p,576i,576p,720p,1080i, 1080p,4Kx2K@60H | ||
DVI:480i,480p,576i,576p,720p,1080i,1080p,4Kx2K@30H | ||
VGA:480i,480p,576i,576p,720p,1080i,1080p | ||
USB:480i,480p,576i,576p,720p,1080i,1080p | ||
Audio input | PC Audio:L/R RCA input,0.2 ~ 2.0Vrms | |
The above parameters are for reference only. The actual requirements prevail | ||
Android configuration | CPU | Quad-core processor |
RAM | 1GB\2GB\4GB\8G | |
ROM | 16GB\32GB\64GB | |
Web support | RJ45 Network cable,WiFi,Bluetooth 4.0 | |
Port | USB,RJ45,HDMI out,Headphone socket,TF card slot | |
Serial port | RS232,RS485,TTL | |
System version | Android 7.1.2,Android 9.0,Android 11, | |
software | Multimedia information release system software and management background | |
The above parameters are for reference only. The actual requirements prevail | ||
PC configuration | CPU | I3\I5\I7 (3rd, 4th, 6th, 7th, 8th generation....) |
RAM | 4GB\8GB\16GB\32G | |
SSD | 64GB\128GB\256GB\512GB | |
Web support | RJ45 Network cable,WiFi,Bluetoot | |
Port | USB,RJ45,HDMI out,VGA out,Audio out | |
Serial port | RS232,RS485,TTL | |
System version | Windows 7,Windows 8,Windows 10,Windows 11 | |
The above parameters are for reference only. The actual requirements prevail | ||
Touch parameter | Touch type | Multi point infrared touch |
Touch resolution | 1920*1080 | |
Scanning speed | 50P/S | |
Positioning accuracy | ±2mm | |
Response speed | 6ms | |
Effective sensing area | Based on the display area of the device | |
Working humidity | 10~98% | |
Fuselage technology | Appearance design | Novel and beautiful, reasonable layout, wiring standard. Four-class narrow edge structure, ergonomic design; |
Fuselage material | Aluminum profile metal spray paint,cold-rolled steel plate,durable,compression resistance is not easy to deformation,cabinet and fixed backplane components tightly | |
Appearance technology | Aluminum profile wire drawing oxidation treatment | |
LCD surface protection | Ultra transparent tempered glass protection | |
Surface treatment | Aluminum paint sleeve: high-gloss paint/industrial paint, no need to worry about falling off or rust; Corrosion resistant, easy to clean overall. | |
Power source | Built-in safe and reliable power external lead and special socket (with anti-static grounding design) | |
Audio speaker | Built-in full frequency audio speaker *2 | |
ON-OF | No need to open the cabinet,directly external reset switch,convenient and quick | |
Power input | 100~240V 50/60Hz | |
Machine size | Reference size:1859.9*680.5*75mm | |
mountings | Machine base, screw, power cord, certificate, warranty card, WiFi antenna, remote control |
